Name:	C hook
Inquiry

WLL:5T-50T

Safety:4:1-6:1

It's made by high-quality alloy steel and the use of mechanical design principles from processing.

Apply to steel plate's horizontal hoisting

Working load limit	Coil width mm	The diameter of inner coil r mm	Inner width	Inner height	Itself weight kg
3T	300-500	≥400	500	450	350
5T	750-900	≥400	900	500	450
	900-1100	≥506	1100	600	650
	1100-1300	≥506	1300	600	800
10T	750-900	≥506	900	650	600
	900-1120	≥506	1120	850	900
	1100-1300	≥506	1300	750	1000
	1300-1500	≥506	1500	850	1200
15T	900-1100	≥506	1100	850	1200
15T	1100-1500	≥506	1500	850	1600
25T	900-1100	≥506	1100	860	1800
25T	1100-1500	≥506	1500	860	2500
30T	1400-1660	≥506	1660	850	3400
