| Name: | Four ropes Grab Bucket |
|---|---|
| Inquiry |
Product Description
Specifications
Several forms of four ropes, pair ropes and one rope, fit various crane, and used for bulk cargo of homogeneous
granularity
Four ropes Grab Bucket
There are several forms of four ropes, pair ropes and one rope, fit various crane, and used for bulk cargo of
homogeneous granularity (average granularity ≤30mm,maximum granularity≤100mm.)
Following is an example for your reference only.
Performance:
The specification of the rope dual scoop grab bucket:
Four roe ore grab | TZD-36/13.1-P-4 |
Capacity - 36 Ton | 36T |
Ore / Pellet Density | 30-100MM |
Angle of repose | 27.5° |
Grab capacity | 13.1 M3 |
Own Weight | 11.1T |
Crane Load ( 1.9 t/Cu.Mtr) | 1.9T/CU.M |
Dia of closing Rope - mm | Φ36MM |
Dia of Pulleys - mm | Φ720MM(DIA) |
No of Pulleys | 8PCS, 5-FOLD |
Closing Rope Balance | BALANCE BY ARM |
Holding Rope Balance | BALANCE BY BEAM |
Dist Betn closing ropes | 360MM |
Dist Betn holding ropes | 900MM |
Height Open | 5463MM |
Height Closed | 4598MM |
Width | 3910MM |
Spread | 4772MM |
Scale Length | 3170MM |
Closing Rope Length | 25854MM |
Rope Withdrawn Length | 12943MM |
Grab Scale Plates | Hardox-400 |
Grab Scale Knives | Hardox-400 |
Arms | Q345(16Mn) |
Pulleys | Q345(16Mn) |
Pulley Blocks | Q345(16Mn) |
Pulley Pins | 45# |
Guide Rollers | 42CrMo |
